GEP-1058: Route Inclusion and Delegation

  • Issue: #1058
  • Status: Provisional

TLDR

Add support for a 2-tier hierarchy of route configuration to allow partial delegation of route settings and, provide more flexibility in how route configurations are organized and managed.

HTTPRoute Delegation Capabilities

Matching

Capability Importance for Delegation Complexity Implementation Details
Hostnames ? Moderate A three way intersection between Gateway, Parent Route, and Child Route hostnames
Prefix Path on Parent, Prefix or Exact on Child High Low Prefix path match of parent is prepended to child path match, child can support exact or prefix path matching
Exact Path on Parent Low Moderate Would require only "/" matches on child route
Exact Path on Child High Low Prefix path match of parent is prepended to child path match, child can support exact or prefix path matching
Regex Path on Parent or Child Low Impossible Maybe some complex merging is possible here, but I can't think of a good solution
Exact Header on Parent and Child Moderate Low Merge header matches, when duplicate keys appear, treat identically to duplicate match keys in same route
Regex Header on Parent and Child Low Low Merge header matches, when duplicate keys appear, treat identically to duplicate match keys in same route
Exact Query Param on Parent and Child Moderate Low Merge query param matches, when duplicate keys appear, treat identically to duplicate match keys in same route
Regex Query Param on Parent and Child Low Low Merge query param matches, when duplicate keys appear, treat identically to duplicate match keys in same route
Method on Parent and Child Low Low If methods don't overlap, no requests match, potentially surface in status

Filters

Capability Importance for Delegation Complexity Implementation Details
RequestHeaderModifier on Parent and Child Moderate High The order of operations becomes the most important factor here. If we can confirm that all implementations can support an arbitary order of operations for Add, Set, and Remove operations, we could simply specify that configuration on child routes would be applied after parent routes.
RequestMirror on Parent and Child Low High Many implementations can only support mirroring a request to one destination. We could support Parent or child, or state that one overrode the other
RequestRedirect on Parent Low Impossible Redirects simply don't make sense on parents that are delegating.
RequestRedirect on Child Moderate Low Redirects should be possible if they are only configured on child Route rules.
URLRewrite on Parent and Child Low Impossible It would be very difficult, maybe impossible, to merge this configuration.
URLRewrite on Parent or Child Low Moderate Rewrite configuration should be possible on either the parent or child, but not both at the same time.

Open Questions

How do we handle multiple matches?

Parent Route:

matches:
- path:
  - prefix: /foo
- path:
  - prefix: /bar
delegateToNamespace: foo

Child Route:

matches:
- path:
  - prefix: /baz
  • Does the child route match /foo/bar and /bar/baz?
  • Would it be preferable to require the child route to specify the full path?
  • How does this interact with potential matching conflicts for headers or query params?

Parent Route:

matches:
- method: GET
  path:
  - prefix: /foo
- method: POST
  path:
  - prefix: /bar
delegateToNamespace: foo

Child Route:

matches:
- method: GET
  path:
  - prefix: /baz
  • Does this only match GET /foo/baz?
